Product Demo – “Bushing Assembly System with Robotic Loading”

I recorded, edited, and narrated this product demonstration video for Matrix. The small footprint of weldment enclosures and rigid walls presents some difficulty shooting, but it was important for the company to highlight the bushing press since it is a somewhat unique system in their catalogue. The system features a Read more…

By Evan Boldt, 4 years2020-09-07 ago

Product Demo – “Drawer Fed Automation with Palletization”

This is a video that I only edited and narrated due to time constraints programming and installing other projects. The system had a lot of unique features to demonstrate like the drawer feed system, laser engraving, and washing, drying, and palletizing.

By Evan Boldt, 4 years2020-09-06 ago

Retrofit to extend conveyor that was unsupported by original vendor.

Product Demo – “Retrofitting Unsupported Equipment – Conveyor Addition with Robotic Loading”

This is a system that I programmed and installed and also recorded, edited, and narrated the video for. I programmed the PLC and HMI for this system that loads a FANUC ROBODRILL that had been previously manually tended while controlling a retrofitted spurr on an existing conveyor line. Installation required Read more…

By Evan Boldt, 4 years2020-09-06 ago

Product Demo – “Robotic Cleaning and Gauging of Small Parts”

One of the first videos I created for Matrix. Demonstrates an inline automated gauging solution.

By Evan Boldt, 4 years2020-09-05 ago

Product Demo – “Robotic Loading and Gauging for Engine Casings”

I quickly edited some footage that a coworker recorded on a GoPro that turns out to be one of our better videos despite the lower quality footage due to the fact that it was able to be recorded at the customer’s facility once fully operational. The system loads somewhat large Read more…

By Evan Boldt, 4 years2020-09-04 ago

Screenshot of demo video showing a deburr with four brushes and a knockoff

Product Demo – “Multidirectional Brush Deburring With Knockoff Hard Tool”

Matrix has built a lot of unique deburr systems, so it’s important to distinguish each one. I programmed the Siemens drives, PLC, and HMI, which includes the control of the conveyor, and its RFIDs, and the robot.

By Evan Boldt, 6 years ago

Product Demo – “Machine Tending Retrofit Adding Automation”

This is a relatively simple system, so the video is much shorter than others. However, it’s important to show that options exist beyond just making new systems. I taught the Fanuc robot and reprogrammed the PLC in the machine to add an interface for the retrofitted automation.

By Evan Boldt, 6 years2018-07-21 ago

Product Demo – “Stainless Steel Conveyor with Intelligent Traffic Management”

This one is kind of funny. It was recorded on an iPhone 6S propped up on top of a section 4×4 wood without any consideration that it would ever be edited together. So the video is an exercise in making the most out of limited footage. I actually programmed the Read more…

By Evan Boldt, 6 years2018-07-21 ago

Product Demo – “High Volume Tending with Vision Inspection”

This video was just shot on a GoPro Hero 6 and iPhone X. The video quality is good enough, but what it shows and the story it tells is what is really important, and I think that’s where this one really succeeds. It’s a very complex system and there is Read more…

By Evan Boldt, 6 years2018-07-21 ago

Screenshot of video I did voiceover for for a robotic automation system.

Voiceover for Robot Commercial

I did the voiceover for this video, but did not shoot or edit it. It was one of my first attempts, so there are some issues with noise. Before this system was retrofitted for another customer, I had programmed the HMI for it.

By Evan Boldt, 6 years2018-07-14 ago
